FPGAに 32bitマイコン ZipCPUの CPUを実装して gccで開発する方法【gcc】

sudo apt install -y flex bison libbison-dev libgmp-dev libmpfr-dev libmpc-dev bc
sudo apt install -y verilator
sudo apt install -y libelf-dev
sudo apt install -y ncurses-dev ctags

cd
git clone --depth 1 https://github.com/ZipCPU/zipcpu --depth 1
cd zipcpu

# just type "make"
make

export PATH=$PATH:`pwd`/sw/install/cross-tools/bin
export | grep PATH

# Running the test file
cd bench/asm
make simtest

# build a disassembly file
make simtest.txt

# change into the Verilator based simulation directory
cd ../..
cd sim/verilator

# The first automated test just runs the test file
# https://github.com/ZipCPU/zipcpu/blob/master/bench/asm/simtest.s
./zipsys_tb -s ../../bench/asm/simtest

Running in non-interactive mode, via step commands
Sim done
SUCCESS!

Clocks used         : 000003aa
Instructions Issued : 0000028f
Tick Count          : 00000ebf
Instructions / Clock: 0.70
SUCCESS!

# The second automated test simulates
./zipsys_tb -a ../../bench/asm/simtest

Running in non-interactive mode
Sim done
SUCCESS!

Clocks used         : 00000831
Instructions Issued : 0000028e
Tick Count          : 00000856
Instructions / Clock: 0.31
SUCCESS!

# These two tests are so valuable to me
make test

# There’s a third way to run the test as well-the interactive test
make itest

# Interactive !!

checking for the correct version of gmp.h... no
configure: error: Building GCC requires GMP 4.2+, MPFR 3.1.0+ and MPC 0.8.0+.
Try the --with-gmp, --with-mpfr and/or --with-mpc options to specify
their locations.  Source code for these libraries can be found at
their respective hosting sites as well as at
https://gcc.gnu.org/pub/gcc/infrastructure/.  See also
http://gcc.gnu.org/install/prerequisites.html for additional info.  If
you obtained GMP, MPFR and/or MPC from a vendor distribution package,
make sure that you have installed both the libraries and the header
files.  They may be located in separate packages.
Makefile:184: recipe for target 'gcc-10.3.0-zip/nonce.txt' failed
make[1]: [gcc-10.3.0-zip/nonce.txt] Error 1 (ignored)
touch gcc-10.3.0-zip/nonce.txt
cc gcc-10.3.0-zip/gcc/config/zip/genzipops.c -o genzipops
./genzipops gcc-10.3.0-zip/gcc/config/zip/zip-ops.md
bash -c "if [[ ! -e build-gcc ]]; then bash gcc-script.sh; fi"
touch build-gcc/nonce.txt
make --no-print-directory --directory=build-gcc all-host
make[2]: *** No rule to make target 'all-host'.  Stop.
Makefile:207: recipe for target 'gcc-host' failed
make[1]: *** [gcc-host] Error 2
Makefile:80: recipe for target 'sw' failed
make: *** [sw] Error 2
