Google Android開発環境の構築 SDK r10版

# This file is automatically generated by Android Tools.
# Do not modify this file -- YOUR CHANGES WILL BE ERASED!
#
# This file must be checked in Version Control Systems.
#
# To customize properties used by the Ant build system use,
# "build.properties", and override values to adapt the script to your
# project structure.

# Project target.
target=android-4
proguard.config=proguard.cfg

-obfuscate:
    [mkdir] Created dir: D:\Android\Project\ProGuardTest\bin\proguard
      [jar] Building jar: D:\Android\Project\ProGuardTest\bin\proguard\original.jar
 [proguard] ProGuard, version 4.4
 [proguard] ProGuard is released under the GNU General Public License. The autho
rs of all
 [proguard] programs or plugins that link to it (com.android.ant, ...) therefore

 [proguard] must ensure that these programs carry the GNU General Public License
 as well.
 [proguard] Reading input...

　～～　省略　～～

retrace.bat [-verbose] mapping.txt [<stacktrace_file>]

[javac] D:\Android\Project\hello\src\com\example\hello\Hello.java:**:
警告: この文字は、エンコーディング ascii にマップできません。

        <javac encoding="utf-8" target="1.5" debug="true" extdirs=""
                destdir="${out.classes.absolute.dir}"
                bootclasspathref="android.target.classpath"

    <!-- compilation options -->
    <property name="java.encoding" value="utf-8" />
    <property name="java.target" value="1.5" />
    <property name="java.source" value="1.5" />

compile:
    [javac] D:\Android\android-sdk\tools\ant\main_rules.xml:361:
      warning: 'includeantruntime' was not set, defaulting to build.sysclasspath=last;
        set to false for repeatable builds







●Android SDK r12以降で発生？



No resource found @android:style/WindowTitle

No resource found @android:style/WindowTitleBackground

　等のエラーが発生する。



　エラーの症状

 [aapt.exe] hoge\res\values\styles.xml:123: error: Error retrieving parent for item: No resource found that matches the given name '@android:style/Widget.TextView.ListSeparator'.

 [aapt.exe] hoge\res\values\styles.xml:234: error: Error retrieving parent for item: No resource found that matches the given name '@android:style/WindowTitle'.

 [aapt.exe] hoge\res\values\styles.xml:345: error: Error retrieving parent for item: No resource found that matches the given name '@android:style/WindowTitleBackground'.

　原因

　"@android:style/～"の幾つかが使用禁止になったため。



　回避方法

"@android:style/WindowTitle"

　を

"@*android:style/WindowTitle"

　にする。






●AdSenseを組み込んでいると ProGuardでエラーが出る。



AdSense AFMAUtil ProGuard Exception = [java.lang.ArrayIndexOutOfBoundsException]



　エラーの内容

 [proguard] ProGuard, version 4.4
 [proguard] ProGuard is released under the GNU General Public License. The authors of all
 [proguard] programs or plugins that link to it (com.android.ant, ...) therefore
 [proguard] must ensure that these programs carry the GNU General Public License as well.
 [proguard] Reading input...
 [proguard] Initializing...
 [proguard] Note: com.google.ads.AFMAUtil:
   can't find dynamically referenced class android.os.SystemProperties
 [proguard] Note: com.google.ads.AFMAUtil accesses a declared method
   'get(java.lang.String)' dynamically
 [proguard]       Maybe this is library method
   'android.content.ContentValues {java.lang.Object get(java.lang.String); }'
 [proguard]       Maybe this is library method
   'android.hardware.Camera$Parameters { java.lang.String get(java.lang.String); }'
 [proguard]       Maybe this is library method
   'android.os.Bundle { java.lang.Object get(java.lang.String); }'

　～～　省略　～～

 [proguard] Note: there were 1 accesses to class members by means of introspection.
 [proguard]       You should consider explicitly keeping the mentioned class members
 [proguard]       (using '-keep' or '-keepclassmembers').
 [proguard] Ignoring unused library classes...
 [proguard]   Original number of library classes: 2400
 [proguard]   Final number of library classes:    387
 [proguard] Printing kept classes, fields, and methods...
 [proguard] Shrinking...
 [proguard] Printing usage to [D:\Android\Project\XXX\\bin\proguard\usage.txt]...
 [proguard] Removing unused program classes and class elements...
 [proguard]   Original number of program classes: 91
 [proguard]   Final number of program classes:    66
 [proguard] Optimizing...
 [proguard] Unexpected error while performing partial evaluation:
 [proguard]   Class       = [com/google/ads/AFMAUtil]
 [proguard]   Method      = [c([B[B)[B]
 [proguard]   Exception   = [java.lang.ArrayIndexOutOfBoundsException] (-1)

BUILD FAILED
D:\Android\android-sdk\tools\ant\main_rules.xml:431:
  java.lang.ArrayIndexOutOfBoundsException: -1
        at proguard.optimize.peephole.BranchTargetFinder.visitConstantInstruction
          (BranchTargetFinder.java:496)




　解決方法

proguard.cfg

　に

-dontoptimize

　を追加する。



　※ -keep 指定で行けそうな気がするが、指定方法が分からない。



　元の proguard.cfgのファイルはここにある。

D:\Android\android-sdk\tools\lib



proguard.cfg

-optimizationpasses 5
-dontusemixedcaseclassnames
-dontskipnonpubliclibraryclasses
-dontpreverify
-verbose
-optimizations !code/simplification/arithmetic,!field/*,!class/merging/*

-keep public class * extends android.app.Activity
-keep public class * extends android.app.Application
-keep public class * extends android.app.Service
-keep public class * extends android.content.BroadcastReceiver
-keep public class * extends android.content.ContentProvider
-keep public class com.android.vending.licensing.ILicensingService

　～～　省略　～～

-keep class * implements android.os.Parcelable {
  public static final android.os.Parcelable$Creator *;
}

-dontoptimize







●strings.xmlで error: Error parsing XML: not well-formed (invalid token)



 [aapt.exe] hoge_project\res\values\strings.xml:xx: error: Error parsing XML: not well-formed (invalid token)



 formatted="false"を追加



 <string name="hoge_string" formatted="false">Hoge String(s)</string>






●AdMobを組み込んで ProGuard最適化すると実行時に「予期せず停止しました」のエラーが出る。



※ この情報は2011/4以降の新バージョンの AdMobです。



　ProGuard AdMob InflateException LayoutInflater com.google.ads.GoogleAdView



　解決方法

proguard.cfg

　に

-keep public class com.google.ads.GoogleAdView

　を追加する。




●AdMobを組み込んで ProGuard最適化すると実行時に「予期せず停止しました」のエラーが出る。



※ この情報は旧バージョンの AdMobです。



　ProGuard AdMob InflateException LayoutInflater com.admob.android.ads.AdView



　解決方法

proguard.cfg

　に

-keep public class com.admob.android.ads.AdView

　を追加する。



ProGuardでの AdMobのエラーログ

ERROR/AndroidRuntime(993): java.lang.RuntimeException:
 Unable to start activity ComponentInfo
  {jp.ne.neko.freewing.xxx/jp.ne.neko.freewing.xxx}:
   android.view.InflateException: Binary XML file line #32:
    Error inflating class com.admob.android.ads.AdView
ERROR/AndroidRuntime(993):
 at android.app.ActivityThread.performLaunchActivity(ActivityThread.java:2705)
ERROR/AndroidRuntime(993):
 Caused by: android.view.InflateException:
  Binary XML file line #32: Error inflating class com.admob.android.ads.AdView
ERROR/AndroidRuntime(993):
 at android.view.LayoutInflater.createViewFromTag(LayoutInflater.java:576)







●俺メモ



import android.os.Build.VERSION_CODES



Build.VERSION_CODES



if (Integer.parseInt(Build.VERSION.SDK) < Build.VERSION_CODES.FROYO)

{

 Eclair以下の処理

}





1 int BASE October 2008: The original, first, version of Android.

2 int BASE_1_1 February 2009: First Android update, officially called 1.1.



--- 壁 --- 1.5

3 int CUPCAKE May 2009: Android 1.5.



--- 壁 --- 1.6

4 int DONUT September 2009: Android 1.6.



--- 壁 --- 2.0

5 int ECLAIR November 2009: Android 2.0

Applications targeting this or a later release will get these new changes in behavior

6 int ECLAIR_0_1 December 2009: Android 2.0.1



--- 壁 --- 2.1

7 int ECLAIR_MR1 January 2010: Android 2.1



--- 壁 --- 2.2

8 int FROYO June 2010: Android 2.2



--- 壁 --- 2.3

9 int GINGERBREAD November 2010: Android 2.3

10 int GINGERBREAD_MR1 February 2011: Android 2.3.3.



--- 壁 --- 3.0

11 int HONEYCOMB February 2011: Android 3.0.

12 int HONEYCOMB_MR1 May 2011: Android 3.1.

13 int HONEYCOMB_MR2 June 2011: Android 3.2.



--- 壁 --- 4.0

14 Android 4.0.1 4.0.2 Ice Cream Sandwich

15 Android 4.0.3 Ice Cream Sandwich



--- 番外 ---

10000 int CUR_DEVELOPMENT Magic version number for a current development build, which has not yet turned into an official release.





http://source.android.com/source/build-numbers.html



Code name Version API level

(no code name) 1.0 API level 1

(no code name) 1.1 API level 2

Cupcake 1.5 API level 3, NDK 1

Donut 1.6 API level 4, NDK 2

Eclair 2.0 API level 5

Eclair 2.0.1 API level 6

Eclair 2.1 API level 7, NDK 3

Froyo 2.2.x API level 8, NDK 4

Gingerbread 2.3 - 2.3.2 API level 9, NDK 5

Gingerbread 2.3.3 - 2.3.7 API level 10

Honeycomb 3.0 API level 11

Honeycomb 3.1 API level 12, NDK 6

Honeycomb 3.2.x API level 13

IceCreamSandwich 4.0.1 - 4.0.2 API level 14, NDK 7

IceCreamSandwich 4.0.3 API level 15



--



Build Tag Notes

DRC83 android-1.6_r1.1 earliest Donut version, ADP1, ADP2

DRC92 android-1.6_r1.2

DRD08 android-1.6_r1.3

DRD20 android-1.6_r1.4

DMD64 android-1.6_r1.5 latest Donut version

ESD20 android-2.0_r1 earliest Eclair version

ESD56 android-2.0.1_r1

ERD79 android-2.1_r1 Nexus One

ERE27 android-2.1_r2 Nexus One

EPE54B android-2.1_r2.1p Nexus One

ESE81 android-2.1_r2.1s

EPF21B android-2.1_r2.1p2 latest Eclair version

FRF85B android-2.2_r1 earliest Froyo version, Nexus One

FRF91 android-2.2_r1.1 Nexus One

FRG01B android-2.2_r1.2

FRG22D android-2.2_r1.3

FRG83 android-2.2.1_r1 Nexus One

FRG83D android-2.2.1_r2 Nexus One

FRG83G android-2.2.2_r1 Nexus One

FRK76 android-2.2.3_r1

FRK76C android-2.2.3_r2 latest Froyo version

GRH55 android-2.3_r1 earliest Gingerbread version, Nexus S

GRH78 android-2.3.1_r1 Nexus S

GRH78C android-2.3.2_r1 Nexus S

GRI40 android-2.3.3_r1 Nexus One, Nexus S

GRI54 android-2.3.3_r1.1 Nexus S

GRJ06D android-2.3.4_r0.9 Nexus S 4G

GRJ22 android-2.3.4_r1 Nexus One, Nexus S, Nexus S 4G

GRJ90 android-2.3.5_r1 Nexus S 4G

GRK39C android-2.3.6_r0.9 Nexus S

GRK39F android-2.3.6_r1 Nexus One, Nexus S

GWK74 android-2.3.7_r1 latest Gingerbread version, Nexus S 4G

ITL41D android-4.0.1_r1 earliest IceCreamSandwich version, Galaxy Nexus

ITL41D android-4.0.1_r1.1 Galaxy Nexus

ITL41F android-4.0.1_r1.2 Galaxy Nexus

ICL53F android-4.0.2_r1 Galaxy Nexus

IML74K android-4.0.3_r1 Nexus S

IML77  latest IceCreamSandwich version






●俺メモ



　Android Source Code GitHub

https://github.com/OESF/



　OHA-Android-2.3.4_r1.0

https://github.com/OESF/OHA-Android-2.3.4_r1.0.git

　OHA-Android-2.3.4_r1.0.zip

https://github.com/OESF/OHA-Android-2.3.4_r1.0/zipball/master






●俺メモ

　[Windows XP/VISTA/7][UTILITY][TOOL] APK Multi-Tool

http://forum.xda-developers.com/showthread.php?t=1310151



 [Windows XP/VISTA/7][UTILITY][TOOL] APK Multi-Tool

I am currently working on a major update to the apk manager application as well and changing the name to APK Multi-Tool with some new added features and also to fix some issues with some code errors.





　ApkMultiTools (APK Multi-Tools)

https://github.com/ApkMultiTools



　build/tools/signapk/SignApk.java

　out/host/linux-x86/framework/signapk.jar



http://code.google.com/p/android-apktool/downloads/list
